Home > All Collections > Others > Power Splitter > 1000～26500 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 1000～26500 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 1000～26500 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

1000～26500 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

No.MDC-1/26.5-20S
CONTACT US
  • 1000～26500 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
Description

Specifications

Frequency Range ：1000～20000 MHz

Insertion Loss≤ 1.0dB

VSWR Primary：Type. 1.4 / Max. 1.6

VSWR Secondary：Type. 1.4 / Max. 1.6

Directivity：Min. 10 dB

Frequency Sensitivity：±1.2dB

Nominal Coupling：10±1.5dB

Impedance：50 Ohms

Input/Output Connectors：2.92mm-Female

Power Rating：30W

Operation Temperature：-45℃ ~ +85℃

Surface Finishing：Black paint
