Home > All Collections > Others > Power Splitter > 12400～18000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 12400～18000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 12400～18000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

12400～18000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

No.MDC-12.4/18-20S
CONTACT US
  • 12400～18000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
Description

Specifications

Frequency Range ：12400～18000 MHz

Insertion Loss≤0.5 dB

VSWR Primary< 1.3:1

VSWR Secondary < 1.4:1

Directivity：Min. 12 dB

Frequency Sensitivity：Type. ±0.9dB / Max. ±1.0dB

Nominal Coupling：20±1.0dB

Impedance；50 Ohms

Input/Output Connectors：SMA-Female

Power Rating：Average.50W

Operation Temperature：-45℃ ~ +85℃

Surface Finishing：Sandblasting natural color conductive oxide
