Specifications
Frequency Range：2000～18000 MHz
Insertion Loss≤ 0.5dB
VSWR Primary< 1.5:1
VSWR Secondary < 1.5:1
Directivity：Min. 12 dB
Frequency Sensitivity：Type. ±0.9dB / Max. ±1.0dB
Nominal Coupling：20±1.0dB
Impedance：50 Ohms
Input/Output Connectors：SMA-Female / SMA-Male;
Power Rating：Average.50W
Operation Temperature：-45℃ ~ +85℃
Surface Finishing：Black paint
