  • 2000～40000 MHz 2.92mm Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 2000～40000 MHz 2.92mm Female Power Divider 50 Ohm Wide-Band Signal Splitter

2000～40000 MHz 2.92mm Female Power Divider 50 Ohm Wide-Band Signal Splitter

No.MDC-2/40-16K
CONTACT US
  • 2000～40000 MHz 2.92mm Female Power Divider 50 Ohm Wide-Band Signal Splitter
Description

Specifications

Frequency Range ：2000～40000 MHz

Insertion Loss≤ 1.5 dB

VSWR Primary：Typ.1.4 / Max.1.6

VSWR Secondary：Typ.1.4 / Max.1.6

Directivity：Min. 10 dB

Frequency Sensitivity：Type. ±0.9dB / Max. ±1.0dB

Nominal Coupling：16 ±1.8dB

Impedance：50 Ohms

Input/Output Connectors：2.92mm-Female

Power Rating：Average.30W

Operation Temperature：-40℃ ~ +85℃

Surface Finishing：Black paint
