2000～6000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

No.MDC-2/6-30S
CONTACT US
  • 2000～6000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
Description

Specifications

Frequency Range：2000～6000 MHz

Insertion Loss≤ 0.5dB

VSWR Primary：Max. 1.30

VSWR Secondary：Max. 1.30

Directivity：Min. 15dB

Nominal Coupling：30±1.2dB

Impedance：50 Ohms

Input/Output Connectors：SMA-Female

Power Rating：30W

Operation Temperature：-35℃ ~ +75℃

Surface Finishing ： Sandblasting natural color conductive oxide
