Specifications
Frequency Range ：500～18000 MHz
Insertion Loss≤ 1.5 dB
VSWR Primary：Max.1.50
VSWR Secondary：Max.1.50
Directivity：0.5-12.4GHz ≥15 dB ＆ 12.4-18GHz ≥12dB
Frequency Sensitivity：Type. ±0.9dB / Max. ±1.0dB
Nominal Coupling：10 ±1.0dB
Impedance：50 Ohms
Input/Output Connectors：SMA-Female
Power Rating：Average.30W
Operation Temperature：-45℃ ~ +85℃
Surface Finishing ：Sandblasting natural color conductive oxide
