500～26500 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

No.MDC-0.5/26.5-20S
CONTACT US
  • 500～26500 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
Description

Specifications

Frequency Range ：500～26500 MHz

Insertion Loss≤ 2.5 dB

VSWR Primary：Typ.1.24 / Max.1.7

VSWR Secondary：Typ.1.24 / Max.1.7

Directivity：Min. 10 dB

Frequency Sensitivity：Type. ±1.0dB / Max. ±1.5dB

Nominal Coupling：20 ±2.5dB

Impedance：50 Ohms

Input/Output Connectors：SMA-Female

Power Rating：Average.30W

Operation Temperature：-45℃ ~ +85℃

Surface Finishing：Black paint
