Home > All Collections > Others > Power Splitter > 500～40000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 500～40000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 500～40000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

500～40000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

No.MDC-0.5/40-20K
CONTACT US
  • 500～40000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
Description

Specifications

Frequency Range ：500～40000 MHz

Insertion Loss≤ 3.0 dB

VSWR Primary：Typ.1.28 / Max.1.7

VSWR Secondary：Typ.1.28 / Max.1.7

Directivity：Min. 8 dB

Frequency Sensitivity：Type. ±1.2dB / Max. ±1.9dB

Nominal Coupling：20 ±2.8dB

Impedance：50 Ohms

Input/Output Connectors：2.92-Female

Power Rating：Average.30W

Operation Temperature：-45℃ ~ +85℃

Surface Finishing：Black paint
