600～4000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

No.MDC-0.6/4-10S
CONTACT US
  • 600～4000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
Description

Specifications

Frequency Range ：600～4000 MHz

Insertion Loss≤ 1.0 dB

VSWR Primary：Typ.1.18 / Max.1.25

VSWR Secondary：Typ.1.18 / Max.1.25

Directivity：Min. 20dB

Frequency Sensitivity：Type. ±0.9dB / Max. ±1.0dB

Nominal Coupling：10 ±1.0dB

Impedance：50 Ohms

Input/Output Connectors：SMA-Female

Power Rating：Average.30W

Operation Temperature：-35℃ ~ +75℃

Surface Finishing：Sandblasting natural color conductive oxide
