Home > All Collections > Others > Power Splitter > 6000～18000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 6000～18000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 6000～18000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

6000～18000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

No.MDC-6/18-10S
CONTACT US
  • 6000～18000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
Description

Specifications

Frequency Range :6000～18000 MHz

Insertion Loss≤1.0 dB

VSWR Primary:Typ.1.18 / Max.1.50

VSWR Secondary:Typ.1.18 / Max.1.50

Directivity:Min. 12 dB

Frequency Sensitivity:Type. ±0.9dB / Max. ±1.0dB

Nominal Coupling:10 ±1.0dB

Impedance:50 Ohms

Input/Output Connectors:SMA-Female

Power Rating:Average.30W

Operation Temperature:-45℃ ~ +85℃

Surface Finishing:Sandblasting natural color conductive oxide
