Home > All Collections > Others > Power Splitter > 6000～18200 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 6000～18200 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 6000～18200 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

6000～18200 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

No.MDC-6/18.2-30S
CONTACT US
  • 6000～18200 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
Description

Specifications

Frequency Range :6000～18200 MHz

Insertion Loss≤0.6 dB

VSWR Primary:Typ.1.18 / Max.1.5

VSWR Secondary:Typ.1.18 / Max.1.5

Directivity:Min. 12 dB

Frequency Sensitivity:Type. ±0.9dB / Max. ±1.0dB

Nominal Coupling:30 ±1.0dB

Impedance:50 Ohms

Input/Output Connectors:SMA-Female

Power Rating:Average.30W

Operation Temperature:-40℃ ~ +85℃

Surface Finishing:Black paint
