6000～26500 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

No.MDC-6/26.5-30S
CONTACT US
  • 6000～26500 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
Description

Specifications

Frequency Range:6000～26500 MHz

Insertion Loss≤1.2 dB

VSWR Primary:Typ.1.4 / Max.1.70

VSWR Secondary:Typ.1.4 / Max.1.70

Directivity:Min. 10 dB

Frequency Sensitivity:Max. ±1.2dB

Nominal Coupling:30 ±1.5dB

Impedance:50 Ohms

Input/Output Connectors:SMA-Female

Power Rating:Average.30W

Operation Temperature:-45℃ ~ +85℃

Surface Finishing:Black paint
