Home > All Collections > Others > Power Splitter > 2000~18000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 2000~18000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 2000~18000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

2000~18000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

No.MTH-2/18-S-3
CONTACT US
  • 2000~18000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
Description

Frequency Range ：2000～18000 MHz

Insertion Loss≤ 1.5dB

VSWR <1.45:1

Isolation ：Min. 17 dB

Amplitude Balance：Max. ±0.8dB

Phase Balance：±5°

Impedance：50 Ohms

Input/Output Connectors:SMA-Female

Power Rating:Average.30W

Operation Temperature:-45℃ ~ +85℃

Surface Finishing:Black paint
