Home > All Collections > Others > Power Splitter > 2000~8000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 2000~8000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
  • 2000~8000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

2000~8000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter

No.180°MTH-2/8-S
CONTACT US
  • 2000~8000 MHz SMA Female Power Divider 50 Ohm Wide-Band Signal Splitter
Description

Specifications

Frequency Range ：2000～8000 MHz

Insertion Loss≤ 1.6 dB

Primary VSWR：Max.1.70

Secondary VSWR：Max.1.70

Directivity：Min.15dB

Frequency Sensitivity：±1.0dB

Phase Balance：±11°

Impedance：50 Ohms

Input/Output Connectors：SMA-Female

Power Rating：30W

Operation Temperature：-45℃ ~ +85℃

Surface Finishing：Black paint
